Non-linear droop control

Files
TR Number
Date
2020-09-08
Authors
Journal Title
Journal ISSN
Volume Title
Publisher
United States Patent and Trademark Office
Abstract

Aspects of non-linear droop control are described herein. In one embodiment, a system includes a first power converter or source configured to provide power to a bus, a second power converter or source configured to provide power to the bus, and a load electrically coupled to the bus. The system also includes a controller configured to adjust a droop resistance associated with the first power source according to a continuous non-linear function based on an amount of current supplied to the load by the first power source. The system can also include a second controller configured to adjust a droop resistance associated with the second power source according to the continuous non-linear function (or another continuous non-linear function). The use of the continuous non-linear functions achieves tighter voltage regulation particularly at lower loads and better load sharing at higher loads.

Description
Keywords
Citation
