Cancellation of inductor winding capacitance

Simple item page
dc.contributor.assigneeVirginia Tech Intellectual Properties, Inc.en
dc.contributor.inventorLee, Fred C.en
dc.contributor.inventorWang, Shuoen
dc.date.accessed2016-08-19en
dc.date.accessioned2016-08-24T17:54:50Zen
dc.date.available2016-08-24T17:54:50Zen
dc.date.filed2006-10-24en
dc.date.issued2009-06-30en
dc.description.abstractAn inductor device or filter such as an electromagnetic interference (EMI) filter which includes an inductor provides cancellation of parasitic capacitance of the inductor and extends high frequency performance of the inductor or filter by providing the inductor using split windings and including capacitors to couple signals corresponding to those which are passed by the equivalent parallel capacitance of the inductor to another split winding or an inductor in the ground return path. Cancellation of parasitic capacitance is provided for differential mode and common mode split windings where the split windings may be either inductively coupled or not. Forming the split windings as a bifilar winding to increase coupling coefficient further improves performance and allows cancellation (as distinct from parasitic capacitance reduction) and avoidance of resonance in circuits in which an inductor is not permitted in the ground return path.en
dc.format.mimetypeapplication/pdfen
dc.identifier.applicationnumber11552292en
dc.identifier.patentnumber7554423en
dc.identifier.urihttp://hdl.handle.net/10919/72603en
dc.identifier.urlhttp://pimg-fpiw.uspto.gov/fdd/23/544/075/0.pdfen
dc.language.isoen_USen
dc.publisherUnited States Patent and Trademark Officeen
dc.subject.cpcH01F17/062en
dc.subject.cpcH01F27/34en
dc.subject.cpcH01F27/38en
dc.subject.cpcH03H7/427en
dc.subject.cpcH03H2001/0035en
dc.subject.cpcH03H2001/0057en
dc.subject.cpcH03H2001/0092en
dc.subject.uspc333/185en
dc.subject.uspcother336/229en
dc.titleCancellation of inductor winding capacitanceen
dc.typePatenten
dc.type.dcmitypeTexten
dc.type.patenttypeutilityen
