Electromagnetic interference noise separator
| dc.contributor.assignee | Virginia Tech Intellectual Properties, Inc. | en |
| dc.contributor.inventor | Lee, Fred C. | en |
| dc.contributor.inventor | Wang, Shuo | en |
| dc.date.accessed | 2016-08-19 | en |
| dc.date.accessioned | 2016-08-24T17:55:07Z | en |
| dc.date.available | 2016-08-24T17:55:07Z | en |
| dc.date.filed | 2009-08-26 | en |
| dc.date.issued | 2012-02-28 | en |
| dc.description.abstract | Improved performance of a noise separator circuit capable of separating common mode (CM) and differential mode (DM) components of electromagnetic interference (EMI) noise are provided by arrangement of terminating impedances such that the circuit is fully symmetric with respect of a pair of input ports. The noise separator circuit is further improved by perfecting features for canceling effects of parasitic inductances and capacitances, parasitic capacitance and inductance between circuit connections such as printed circuit board traces, minimizing leakage inductance effects of pairs of coupled inductors and mutual inductance effects between pairs of coupled inductors, providing sufficient magnetizing inductance for low frequency response, and preventing saturation of inductors using switched attenuators, providing a plurality of ground planes, choices of terminating resistors and circuit layout. | en |
| dc.format.mimetype | application/pdf | en |
| dc.identifier.applicationnumber | 12548030 | en |
| dc.identifier.patentnumber | 8125291 | en |
| dc.identifier.uri | http://hdl.handle.net/10919/72675 | en |
| dc.identifier.url | http://pimg-fpiw.uspto.gov/fdd/91/252/081/0.pdf | en |
| dc.language.iso | en_US | en |
| dc.publisher | United States Patent and Trademark Office | en |
| dc.subject.cpc | H03H7/0115 | en |
| dc.subject.cpc | H03H1/0007 | en |
| dc.subject.cpc | H03H2001/0057 | en |
| dc.subject.uspc | 333/32 | en |
| dc.subject.uspcother | 333/12 | en |
| dc.subject.uspcother | 333/177 | en |
| dc.subject.uspcother | 333/181 | en |
| dc.title | Electromagnetic interference noise separator | en |
| dc.type | Patent | en |
| dc.type.dcmitype | Text | en |
| dc.type.patenttype | utility | en |
