Non-linear droop control
| dc.contributor.assignee | Virginia Tech Intellectual Properties, Inc. | en |
| dc.contributor.inventor | Chen, Fang | en |
| dc.contributor.inventor | Burgos, Rolando | en |
| dc.contributor.inventor | Boroyevich, Dushan | en |
| dc.date.accessed | 2021-03-23 | en |
| dc.date.accessioned | 2021-03-25T18:15:46Z | en |
| dc.date.available | 2021-03-25T18:15:46Z | en |
| dc.date.filed | 2016-10-18 | en |
| dc.date.issued | 2020-09-08 | en |
| dc.description.abstract | Aspects of non-linear droop control are described herein. In one embodiment, a system includes a first power converter or source configured to provide power to a bus, a second power converter or source configured to provide power to the bus, and a load electrically coupled to the bus. The system also includes a controller configured to adjust a droop resistance associated with the first power source according to a continuous non-linear function based on an amount of current supplied to the load by the first power source. The system can also include a second controller configured to adjust a droop resistance associated with the second power source according to the continuous non-linear function (or another continuous non-linear function). The use of the continuous non-linear functions achieves tighter voltage regulation particularly at lower loads and better load sharing at higher loads. | en |
| dc.format.mimetype | application/pdf | en |
| dc.identifier.applicationnumber | 15296564 | en |
| dc.identifier.patentnumber | 10770988 | en |
| dc.identifier.uri | http://hdl.handle.net/10919/102848 | en |
| dc.identifier.url | http://pimg-fpiw.uspto.gov/fdd/88/709/107/0.pdf | en |
| dc.language | en | en |
| dc.publisher | United States Patent and Trademark Office | en |
| dc.title | Non-linear droop control | en |
| dc.type | Patent | en |
| dc.type.dcmitype | Text | en |
| dc.type.patenttype | utility | en |
