Multi-parameter X-ray computed tomography
| dc.contributor.assignee | Virginia Tech Intellectual Properties, Inc. | en |
| dc.contributor.inventor | Wang, Ge | en |
| dc.contributor.inventor | Cong, Wenxiang | en |
| dc.date.accessed | 2016-08-19 | en |
| dc.date.accessioned | 2016-08-24T17:55:06Z | en |
| dc.date.available | 2016-08-24T17:55:06Z | en |
| dc.date.filed | 2010-06-04 | en |
| dc.date.issued | 2012-02-21 | en |
| dc.description.abstract | The present invention relates to the field of x-ray imaging. More particularly, embodiments of the invention relate to methods, systems, and apparatus for imaging, which can be used in a wide range of applications, including medical imaging, security screening, and industrial non-destructive testing to name a few. Specifically provided as embodiments of the invention are systems for x-ray imaging comprising: a) a first collimator-and-detector assembly having a first operable configuration to provide at least one first dataset comprising primary x-ray signals as a majority component of its data capable of being presented as a first image of an object subjected to x-ray imaging; b) a second collimator-and-detector assembly having a second operable configuration or wherein the first collimator-and-detector assembly is adjustable to a second configuration to provide at least one second dataset comprising primary and dark-field x-ray signals as a majority component of its data capable of being presented as a second image of the object; and c) a computer operably coupled with the collimator-and-detector assemblies comprising a computer readable medium embedded with processing means for combining the first dataset and the second dataset to extract the dark-field x-ray signals and produce a target image having higher contrast quality than the images based on the first or second dataset alone. Such systems can be configured to comprise at least two collimator-and-detector assemblies or configurations differing with respect to collimator height, collimator aperture, imaging geometry, or distance between an object subjected to the imaging and the collimator-and-detector assembly. | en |
| dc.format.mimetype | application/pdf | en |
| dc.identifier.applicationnumber | 12794160 | en |
| dc.identifier.patentnumber | 8121249 | en |
| dc.identifier.uri | http://hdl.handle.net/10919/72673 | en |
| dc.identifier.url | http://pimg-fpiw.uspto.gov/fdd/49/212/081/0.pdf | en |
| dc.language.iso | en_US | en |
| dc.publisher | United States Patent and Trademark Office | en |
| dc.subject.cpc | A61B6/06 | en |
| dc.subject.cpc | A61B6/032 | en |
| dc.subject.cpc | A61B6/4291 | en |
| dc.subject.cpc | A61B6/583 | en |
| dc.subject.uspc | 378/6 | en |
| dc.subject.uspcother | 378/7 | en |
| dc.subject.uspcother | 378/70 | en |
| dc.subject.uspcother | 378/86 | en |
| dc.title | Multi-parameter X-ray computed tomography | en |
| dc.type | Patent | en |
| dc.type.dcmitype | Text | en |
| dc.type.patenttype | utility | en |
