Multiphase clamp coupled-buck converter and magnetic integration
| dc.contributor.assignee | Virginia Tech Intellectual Properties, Inc. | en |
| dc.contributor.inventor | Lee, Fred C. | en |
| dc.contributor.inventor | Wei, Jia | en |
| dc.contributor.inventor | Xu, Peng | en |
| dc.contributor.inventor | Yao, Kaiwei | en |
| dc.contributor.inventor | Ye, Mao | en |
| dc.date.accessed | 2016-08-19 | en |
| dc.date.accessioned | 2016-08-24T17:54:27Z | en |
| dc.date.available | 2016-08-24T17:54:27Z | en |
| dc.date.filed | 2002-02-22 | en |
| dc.date.issued | 2004-08-31 | en |
| dc.description.abstract | Voltage regulation, transient response and efficiency of a voltage regulator module (VRM) is improved where short duty cycles are necessitated by large differentials of input and output voltage by including at least one clamping of a tap of an inductance in series with an output of each of a plurality of parallel branches or phases which are switched in a complementary fashion or providing coupling between inductors of respective phases. Such coupling between inductors is achieved in a small module with an integrated magnetic structure. Reduced component counts are achieved while deriving built-in input and output filters. Principals of the invention can be extended to isolation applications and push-pull forward converts, in particular. A lossless clamping circuit is also provided allowing spike currents to be suppressed while returning power to the output of the VRM. | en |
| dc.format.mimetype | application/pdf | en |
| dc.identifier.applicationnumber | 10079819 | en |
| dc.identifier.patentnumber | 6784644 | en |
| dc.identifier.uri | http://hdl.handle.net/10919/72497 | en |
| dc.identifier.url | http://pimg-fpiw.uspto.gov/fdd/44/846/067/0.pdf | en |
| dc.language.iso | en_US | en |
| dc.publisher | United States Patent and Trademark Office | en |
| dc.subject.cpc | H02M3/158 | en |
| dc.subject.cpc | H02M3/1584 | en |
| dc.subject.cpc | H02M2001/0064 | en |
| dc.subject.uspc | 323/225 | en |
| dc.subject.uspcother | 323/255 | en |
| dc.subject.uspcother | 323/259 | en |
| dc.subject.uspcother | 363/56.12 | en |
| dc.title | Multiphase clamp coupled-buck converter and magnetic integration | en |
| dc.type | Patent | en |
| dc.type.dcmitype | Text | en |
| dc.type.patenttype | utility | en |
