Heat flux gage

dc.contributor.assignee	Virginia Polytechnic Institute and State University	en
dc.contributor.inventor	Diller, Thomas E.	en
dc.contributor.inventor	Onishi, Shinzo	en
dc.date.accessed	2016-08-19	en
dc.date.accessioned	2016-08-24T17:55:39Z	en
dc.date.available	2016-08-24T17:55:39Z	en
dc.date.filed	1987-10-15	en
dc.date.issued	1988-10-25	en
dc.description.abstract	The invention is a heat flux gage applied to a surface, for the measurement of surface heat transfer. All elements of the gage are thin films, deposited on the surface by sputtering or an equivalent process. The gage comprises a plurality of thermocouple junctions connected as a differential thermopile, with hot and cold junctions on the two faces of a planar thermal resistance element. Electrical insulating and protective layers are deposited between the surface and the gage, and over the exterior of the gage. The gage output signal is a voltage indicative of heat flux.	en
dc.format.mimetype	application/pdf	en
dc.identifier.applicationnumber	7109057	en
dc.identifier.patentnumber	4779994	en
dc.identifier.uri	http://hdl.handle.net/10919/72819	en
dc.identifier.url	http://pimg-fpiw.uspto.gov/fdd/94/799/047/0.pdf	en
dc.language.iso	en_US	en
dc.publisher	United States Patent and Trademark Office	en
dc.subject.cpc	G01K17/20	en
dc.subject.cpc	H01L35/08	en
dc.subject.uspc	136/225	en
dc.subject.uspcother	374/29	en
dc.subject.uspcother	374/30	en
dc.subject.uspcother	374/E17.015	en
dc.title	Heat flux gage	en
dc.type	Patent	en
dc.type.dcmitype	Text	en
dc.type.patenttype	utility	en
