EMI filter and frequency filters having capacitor with inductance cancellation loop
| dc.contributor.assignee | Virginia Tech Intellectual Properties, Inc. | en |
| dc.contributor.inventor | Lee, Fred C. | en |
| dc.contributor.inventor | Odendaal, Willem G. | en |
| dc.contributor.inventor | Wang, Shuo | en |
| dc.date.accessed | 2016-08-19 | en |
| dc.date.accessioned | 2016-08-24T17:54:39Z | en |
| dc.date.available | 2016-08-24T17:54:39Z | en |
| dc.date.filed | 2004-12-17 | en |
| dc.date.issued | 2007-02-20 | en |
| dc.description.abstract | An electromagnetic interference (EMI) filter or frequency filters (e.g. bandpass or band reject filters) in which a capacitor has an inductance cancellation loop. Inductive coupling between capacitors can allow undesired high frequencies to propagate across a filter. This is particularly a concern when the capacitors are oriented in parallel. In the present invention, the inductance cancellation loop is disposed adjacent to one capacitor so that mutual inductance between the capacitors is reduced. The attenuation of the filter at high frequencies is thereby increased. The loop can increase voltage attenuation of an EMI filter by about 20 dB. In another aspect, inductors in the filter are oriented horizontally relative to a circuitboard. Horizontal orientation reduces leakage inductance coupling between the inductors and circuitboard traces, and between the inductor and capacitors, thereby preventing unwanted propagation of high frequencies. Both measures in combination can provide a voltage attenuation increase of 30 dB. | en |
