Development of Methods for Improved Data Integrity and Efficient Testing of Wind Tunnel Models for Dynamic Test Conditions in Unsteady and Nonlinear Flight Regimes

TR Number
Journal Title
Journal ISSN
Volume Title
Virginia Tech

Today's high performance aircraft are operating in expanded flight envelopes, often maneuvering at high angular rates at high angles-of-attack, even above maximum lift. Current aerodynamic models are inadequate in predicting flight characteristics in the expanded envelope, such as rapid aircraft departures and other unusual motions. Unsteady flows of aircraft are of real concern. The ability to accurately measure aerodynamic loads directly impacts the ability to accurately model and predict flight. Current wind tunnel testing techniques do not adequately address the data fidelity of a test point under the influence of fluctuating loads and moments. Additionally, forced oscillation test techniques, one of the primary tools used to develop dynamic models, do not currently provide estimates of the uncertainty of the results during an oscillation cycle. Further, in testing models across a range of flight conditions, there are frequently parts of the envelope which are well behaved and require few data points to arrive at a sound answer, and other parts of the envelope where the responses are much more active and require a large sample of data to arrive at an answer with statistical significance. Currently, test methods do not factor changes of flow physics into data acquisition schemes, so in many cases data are obtained over more iterations than required, or insufficient data may be obtained to determine a valid estimate. Methods of providing a measure of data integrity for static and forced oscillation test techniques are presented with examples. A method for optimizing required forced oscillation cycles based on decay of uncertainty gradients and balance tolerances is also presented.

Static, Forced Oscillation, Data Integrity, Efficient Testing, Wind Tunnel Testing, Uncertainty
